DensArmor Plus® Interior Panel
DensArmor Plus® Interior Panels, which feature fiberglass mats instead of the paper facings used on the surface of traditional gypsum board products, resist mould growth. They’re ideal for areas prone to high humidity such as basements and residential bathrooms, and are ideal for commercial installations. They are designed for direct attachment with screws or nails to timber and metal framing or existing surfaces. They may be used as a covering material for flat or curved structures.
- A1 Reaction to Fire classification in accordance with BS EN 13501-1
- Non-combustible as described and tested in accordance with ASTM E136 or CAN/ULC S114
- Resistant to mould – ASTM D3273
- Dimensionally stable and moisture resistant
Product Details
DensArmor Plus® Interior Panels, which feature fiberglass mats instead of the paper facings used on the surface of traditional gypsum board products, resist mould growth. They’re ideal for areas prone to high humidity and are ideal for commercial installations.
DensArmor Plus® Interior Panels have fiberglass mats for superior mould and moisture resistance compared to paper-faced drywall.
- Fiberglass mats, instead of paper facings, eliminate a potential food source for mould growth and may reduce remediation and scheduling delays associated with paper-faced drywall.
- Used before a construction is weather-tight, DensArmor Plus® Interior Panels stand up to ambient moisture and incidental wettings during and after construction.
- Backed with a limited warranty against delamination and deterioration for up to 12 months of exposure, during construction, to normal weather conditions. For complete warranty details, visit www.buildgp.com/warranties.
DensArmor Plus® Interior Panels, which feature fiberglass mats instead of the paper facings used on the surface of traditional gypsum board products, resist mold growth. When tested, as manufactured, in accordance with ASTM D3273, DensArmor Plus® Interior Panels have scored a 10, the highest level of performance for mould resistance under the ASTM D3273 test method, a testing method set by ASTM International, which develops testing guidelines and procedures for building materials, products, systems and services. The score of 10, in the ASTM D3273 test, indicates no mould growth in a 4-week controlled laboratory test. In addition, the mould resistance of DensArmor Plus® Interior Panels have been validated by UL Environment and listed in its Sustainable Product Guide utilizing microbial resistant testing based on ASTM Standard D6329-98. The mould resistance of any building product when used in actual job site conditions may not produce the same results as were achieved in the controlled, laboratory setting. No material can be considered mould proof. When properly used with good design, handling and construction practices, DensArmor Plus® Interior Panels provide increased mould resistance compared to standard paper-faced gypsum products. For additional information, go to www.buildgp.com/safetyinfo.
DensArmor Plus® Interior Panels are the first gypsum panels to be certified by UL Environment, an independent safety science company, as GREENGUARD and GREENGUARD Gold for low VOC emissions and are included in UL Environment’s Sustainable Product Guide.
Product Specifications
Physical Properties
| Thickness | 12.7 mm (1/2 inch) |
| Width, nominal | 1219 mm ± 2.4 mm |
| Length | 2438, 3658 ± 6.4 mm |
| Weight, nominal | 9.8 kg/m2 (2.0 lbs/ft2) |
| Humidified Deflection | < 6.4 mm (1/4 inch) 1, 2 |
| Thermal Conductivity | 0.17 W/m·K 3 |
| Thickness | 15.9 mm (5/8 inch) |
| Width, nominal | 1219 mm ± 2.4 mm |
| Length | 2438, 3658 ± 6.4 mm |
| Weight, nominal | 12.2 kg/m2 (2.5 lbs/ft2) |
| Humidified Deflection | < 3 mm (1/8 inch) 1, 2 |
1 Tested in accordance with ASTM C473
2 Specified values per ASTM C1177
3 Tested in accordance with BS EN 12664:2001
